Description
Penetration Grade Bitumen 80/100 is a standard bitumen of the penetration grade classification, which is suitable for road construction and hot asphalt production. It is mostly used in cold regions.
Application of Penetration Grade Bitumen 80/100
- This bitumen is almost loose and is used for colder areas.
- The penetration degree of bitumen is 80/100 according to the standard in the range of 80 to 100.
- The use of penetrating bitumen is mainly in road construction.
- For areas with hotter climates, harder bitumen (lower degree of penetration) is used, and for areas with colder climates, looser bitumen (higher degree of penetration) is used.
Specification of Penetration Grade Bitumen 80/100
|
Description |
Unit | Limit | Test Method |
|
Density@25°C |
Kg/m^3 |
1000-1050 |
ASTM D70 or D3289 |
|
Penetration@25°C |
mm/10 |
80-100 |
ASTM D5 |
|
Softening Point |
°C | 45-52 |
ASTM D36 |
|
Ductility@25°C |
cm | 100min | ASTM D113 |
|
Loss on Heating |
wt% | 0.5max |
ASTM D6 |
|
Drop in Penetration after Heating |
% | 20max |
ASTM D5 |
|
Flash Point |
°C | 232min |
ASTM D92 |
|
Solubility in Trichloroethylene |
wt% | 99.0min |
ASTM D2042 |
|
Spot Test |
— | Negative |
A.A.S.H.O.T.102 |
|
Viscosity@60°C |
P | 1000±200 |
ASTM D2171 |
| Viscosity@135°C | cSt | 250min |
ASTM D2170 |
