Description
Penetration Grade Bitumen 70/100 is a standard bitumen of the penetration grade classification, which is suitable for road construction and hot asphalt production and is mostly used in cold regions.
For areas with hotter climates, harder bitumen (lower degree of penetration) is used, and for areas with colder climates, looser bitumen (higher degree of penetration) is used. The penetration degree of bitumen is 70/100 according to the standard in the range of 70 to 100.
Application of Penetration Grade Bitumen 70/100
- road construction
- asphalt pavement
- tack coat or penetration spray
- manufacturer of hot-mix asphalt
- used in the construction of single seals, double seals, and Cape seal
Specification of Penetration Grade Bitumen 70/100
|
Description |
Unit | Limit | Test Method |
|
Density@25°C |
Kg/m^3 | 1010-1060 | ASTM D70 or D3289 |
| Penetration@25°C | mm/10 | 50-70 |
EN 1426 |
| Softening Point | °C | 46-54 |
EN 1427 |
|
Ductility@25°C |
cm | 100 Min | ASTM D113 |
|
Flash Point (Cleveland Open) |
°C | 230 Min | EN ISO 2592 |
| Solubility in Trichloroethylene or Xylene | wt% | 99.0 Min |
EN 12592 or ASTM D2042 |
| Kinematic Viscosity@135°C | mm²/s | 295 Min |
EN 12595 |
|
Resistance to hardening at 163°C: |
|||
|
Change in mass (m/m) |
% | 0.5 Max | EN 12607-1 |
| Retained Penetration 25°C, 100g, 5s (% of original) | % | 50 Min |
EN 1426 |
| Increase in softening point (R&B) | °C | 11 Max |
EN 1427 |
