Description
Penetration Grade Bitumen 60/70 is a standard bitumen of the penetration grade classification based on the international standard. 60/70 penetration grade bitumen is suitable for road construction and hot asphalt production.
The penetration degree of bitumen is 60/70 according to the standard in the range of 60 to 70. This bitumen is almost loose and is used for temperate regions.
Application of Penetration Grade Bitumen 60/70
The use of penetrating bitumen is mainly in road construction. For areas with hotter climates, harder bitumen (lower degree of penetration) is used, and for areas with colder climates, looser bitumen (higher degree of penetration) is used.
Other applications
- Roofing
- Pipe Coating
- Water proofing
- Sound proofing
- Road Construction
- Automotive Industry
- Bridge Waterproofing
- Emulsions and Sealants
- Pavement Rehabilitation
Specification of Penetration Grade Bitumen 60/70
|
Description |
Unit | Limit | Test Method |
|
Density@25°C |
Kg/m^3 | 1010-1060 | ASTM D70 or D3289 |
| Penetration@25°C | mm/10 | 60-70 |
ASTM D5 |
| Softening Point | °C | 49-56 |
ASTM D36 |
| Ductility@25°C | cm | 100min |
ASTM D113 |
|
Loss on Heating |
wt% | 0.2max |
ASTM D6 |
| Drop in Penetration after Heating | % | 20max |
ASTM D5 |
| Flash Point | °C | 232min |
ASTM D92 |
| Solubility in Trichloroethylene | wt% | 99.0min |
ASTM D2042 |
| Spot Test | — | Negative |
A.A.S.H.O.T.102 |
|
Viscosity@60°C |
P | 2000±400 |
ASTM D2171 |
| Viscosity@135°C | cSt | 300min |
ASTM D2170 |
